| General |
| Model |
CKB304v2 |
| Digital Alarm Inputs |
4 x Digital Input Zones |
| Relay Output |
1 x Relay Output (NO/NC) – 100mAmps @24v DC |
| SD Card Slot |
mcroSD/SDHC card slot (Used only for internal Bridge OS – Bridge Warranty Voided if Removed!) |
| Audio Output |
1/8″ (3.5mm) Line Level Output (non-amplified) |
| Reset Button |
Bridge Factory Reset |
| LED Indicators |
| STA (Status) |
Bridge Power – On (Armed Status – Red[Armed] ; Green[Disarmed]) |
| Net (Network) |
Network Connection Indicator |
| DI (Alarm 1-4) |
Digital Input Indicators (Red – Alarm, Off – Normal) |
| Operational |
| Video Source Recommendations |
IP devices with available RTSP Stream. Video Source Requirements:~ D1 Resolution: 720×480 & 6 FPS |
| Video Compression Support |
H.264 |
| Video Authentication Options |
ONVIF, RTSP, HTTP, DAHUA, TVT, HIKVISON, SIGHTLOGIX |
| Video Transmission Security |
TLS/SSL Encryption to Cloud and Central Station |
| Video Analytics Support |
ONVIF Event Messaging Protocol |
| Event Triggers |
Digital Input Triggers, ONVIF Event Messages – Analytics, Network Disconnect – Bridge & Camera Connections |
| Alarm Events |
Transmitted via IP to Central Station Automations |
| Audio In |
Available on supported cameras with audio in the video stream |
| Network |
| Ethernet |
RJ-4510/100/BASE-T Connection |
| Encryption\Security |
TLS/SSL (Secure Socket Layer) |
| Environmental & Electrical |
| Operating Temperature /Humidity |
0C ~ +40°C (32°F ~ 85°F) / Less than 85% RH |
| Bridge Power Source |
12v DC |
| Power Consumption |
400mAmps Peak |
| Digital Input Zones |
Input Voltage Range: 0-12v DC (All Ground Termals Are Common) |
| Relay Output |
max 100mApms @24v DC |
| Arming Input |
Input Voltage Range: 0-12v DC (All Ground Termals Are Common) – 1.87v ADC Reading with no external Connection |
| Mechanical |
| Color / Material |
White / Polycarbonate (PC) |
| Product dimensions / weight |
82mm x 100.7mm x 36mm (3.2″ x 3.9″ x 1.4″), Weight : 170g (0.4lb) |
